SM Fused Fiber Couplers

---------------------------------------------------

Phoenix single mode fiber couplers are designed for the 2 micron, 1300nm, C-band and L-band wavelength ranges. They are made by fusing and tapering two fibers together. The optical signal directed through the input fiber will be split into two at the fusion point. Phoenix can offer a variety of split ratios (with tap ratios from 1% to 50%). The couplers are available in 1x2, 2x2 and 2x4, 3x3, 4x4 configurations.

2000nm Fused Fiber Couplers

3 x 3 Monolithic Fused Fiber Couplers

4 x 4 Monolithic Fused Fiber Couplers

Duel Window Fused Fiber Couplers

Single Window Fused Fiber Couplers

Wide Bandwidth Fused Fiber Couplers
